K8s nexus jenkins

[devops]

K3s cluster එකක jenkins and nexus repository එක deploy කරලා තියෙන්නේ. Nexus repository එකේ privet docker registry එකක් තියනවා. Port 8085. මට මේ docker registry එකට jenkins වල ඉදලා log වෙන්න ඕන.

Any help?

Full dns name එකෙන් නේද access කරන්නඕන?

Error response from daemon: Get "http://localhost:8085/v2/": dial tcp [::1]:8085: connect: connection refused



[jithendra]

K8S service ekak hadala eken expose karanna.



[Commex]

Up



[SDR2000]

Up



[devops]

K8S service ekak hadala eken expose karanna.

---

මම මේ උඩ අහලා තියන issue එක @jithendra කියලා තියන විදියට K8S service ekak hadala eken expose kara ල + Insecure registry configure කරලා fix කරගත්තා.

මට දැන් bitnami/kubectl agent ගෙ ඉඳලත් අර nexus ඇතුලෙ ඉන්න private docker hosted repository එක access කරගන්න ඕන.

Issue :
------ Post added on Feb 16, 2025 at 4:13 PM

---

Failed to pull image "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/docker-hosted-my-repo/my-new-ai-assistant:latest": failed to pull and unpack image "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/docker-hosted-my-repo/my-new-ai-assistant:latest": failed to resolve reference "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/docker-hosted-my-repo/my-new-ai-assistant:latest": failed to do request: Head "https://nexus-service-for-docker-ho...-my-repo/my-new-ai-assistant/manifests/latest": dial tcp: lookup nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local: Try again

kubectl create secret docker-registry nexus-docker-secret \
  --docker-server=http://nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085 \
  --docker-username=admin \
  --docker-password=Devops@1252429 \
  --namespace ai-ns

apiVersion: apps/v1
kind: Deployment
metadata:
  name: ai-assistant-deployment
  namespace: ai-ns
spec:
  replicas: 1
  selector:
    matchLabels:
      app: ai-assistant
  template:
    metadata:
      labels:
        app: ai-assistant
    spec:
      imagePullSecrets:
        - name: nexus-docker-secret  # Reference the created secret
      containers:
      - name: ai-assistant
        image: nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/docker-hosted-my-repo/my-new-ai-assistant:latest
        ports:
        - containerPort: 8501
---
apiVersion: v1
kind: Service
metadata:
  name: ai-assistant-service
  namespace: ai-ns
spec:
  selector:
    app: ai-assistant
  ports:
    - protocol: TCP
      port: 80  # Service port
      targetPort: 8501  # Container port
  type: ClusterIP

------ Post added on Feb 16, 2025 at 4:17 PM



[jithendra]

oya haduwe http registry ekak da? image eka pull karanna try karanne https walin. Ekai pena hetiyata aula



[MemoryHacker]

bump



[dilann]

up



[devops]

oya haduwe http registry ekak da? image eka pull karanna try karanne https walin. Ekai pena hetiyata aula

ow http ekak

Currnt issue : Failed to pull image "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant:v2": failed to pull and unpack image "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant:v2": failed to resolve reference "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant:v2": failed to do request: Head "http://nexus-service-for-docker-hos...y-repository/my-new-ai-assistant/manifests/v2": dial tcp: lookup nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local: Try again

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-ai-app
spec:
  replicas: 1
  selector:
    matchLabels:
      app: my-ai-app
  template:
    metadata:
      labels:
        app: my-ai-app
    spec:
      imagePullSecrets:
        - name: nexus-secret
      containers:
        - name: my-ai-app
          image: nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant:v2
          ports:
            - containerPort: 8080
---
apiVersion: v1
kind: Service
metadata:
  name: my-ai-app
spec:
  selector:
    app: my-ai-app
  ports:
    - protocol: TCP
      port: 80
      targetPort: 8080
  type: ClusterIP

/etc/rancher/k3s/registries.yaml

mirrors:
  nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085:
    endpoint:
      - "http://nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085"

dockerconfigjson

{
        "auths": {
                "nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085": {
                        "auth": "YWRtaW46RGV2b3BzQDEyNTI0xxxx"
                }
        }
}

/ # docker login nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085 -u admin -p Devops@1252429
WARNING! Using --password via the CLI is insecure. Use --password-stdin.
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credential-stores

Login Succeeded
/ # docker push nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant:v2
The push refers to repository [nexus-service-for-docker-hosted-registry.nexus-ns.svc.cluster.local:8085/my-repository/my-new-ai-assistant]
3f26cfdaf332: Layer already exists
aa9f1841ff4a: Layer already exists
e4cd1968f64f: Layer already exists
7e5a568cf7de: Layer already exists
801032f67a6a: Layer already exists
06ee09f93f63: Layer already exists
d0cd4b68ea68: Layer already exists
287621c00364: Layer already exists
369a4df49155: Layer already exists
7914c8f600f5: Layer already exists
v2: digest: sha256:843b9baeb9dde534e5dd5a2c39dc8682e274e5e8d569fc42a2041fb2f947f2c6 size: 2409



[DevOps Engineer]

Bump



[devops]

Help. Up



[u_make_me_sick_]

images store karanne koheda? S3?



[JohnSnow]

up



[devops]

images store karanne koheda? S3?

localy in PV



[Nidarshana_k]

Up



[Djice]

the container runtime does not have access to the image registry inside k8s. you will have to expose the registry with an ingress or a nodeport service and then use it. container runtime lives outside k8s and it cannot query codedns inside k8s. expose the container registry with a nodeport service and use localhost as the hostname



[devops]

the container runtime does not have access to the image registry inside k8s. you will have to expose the registry with an ingress or a nodeport service and then use it. container runtime lives outside k8s and it cannot query codedns inside k8s. expose the container registry with a nodeport service and use localhost as the hostname

Brother, I copied and pasted this message into ChatGPT to get some ideas. Then I solved the problem. Thank you very much!
But I realize that I need to learn more about Kubernetes.
If you have any advice for me, I really appreciate it!



[Djice]

Brother, I copied and pasted this message into ChatGPT to get some ideas. Then I solved the problem. Thank you very much!
But I realize that I need to learn more about Kubernetes.
If you have any advice for me, I really appreciate it!

you're welcome!
I would suggest not using chatgpt to figure out what to do, rather use it only to ask how to do something that you figured out by looking into things. you will have to think about things like networking and how the operating system works this way, and learn things and gain experience. this will help you to advance in your career. also, reading helps.

you can try kubernetes the hard way if you want to dive more into k8s - https://github.com/kelseyhightower/kubernetes-the-hard-way
