ලොකු උදව්වක් ඕන networking field එකේ ඉන්න යාලුවන්ගෙන්.

Shenal2025

Member
Jun 26, 2018
14
8
3
මේකට උත්තර දෙන්න මේ දේවල් ටිකත් කිව්වානම්.

switch එකේ මොඩෙල් එක
Access point වල model
ෆයිල් සර්වර් එකත් එක්ක ශෙයා කරන ෆයිල් වල සයිස්
ස්ලොව් වෙන්නේ specific websitte වලටද. PC or laptop direct switch එකට ගහලා වැඩ කරද්දිත් ඒ slowness එක තියනවාද?
switch -
TL-SG1008D | 8-Port Gigabit Desktop Switch

access point model

TL-WA901ND | 450Mbps Wireless N Access Point

file wala size eka 10mb-40mb range eke thiyenne..
server eke thiyana quickbook kiyana accounting software eke files thama local computer eken open karanne..eka serayak open karata passe use karanna puluwan ai ai load wenna nethiwa.​


specific website walata neme.. hama site ekatamaa gmail.... direct router ekata gahuwth speed test eken 140mbps speed uth hamaba wenawa samahara welatata.

slow wena welawata speed test ekak daala balapan user laptop eken..
test kara. eka eka pc wala eka eka speed pennanne.. okkmama slow wunata passeth samahara lap wala witharak 30mbps speed pennanawa but internet eka gmail load wenawa..
------ Post added on Apr 15, 2021 at 11:33 PM

switch da router da ?
router ekata switch eka gahala thiyenne.. direct gahuwa nam router ekata hari switch ekata hari okkama isolate karala single lap ekak full speed wada..
------ Post added on Apr 15, 2021 at 11:34 PM

  • Like
Reactions: Anatha sinhalu

Shenal2025

Member
Jun 26, 2018
14
8
3
To start with your network setup if fucking insecure (has nothing to do directly with the performance). Incase you don't have the funds try to get a basic firewall setup (something like pfsense)

If the slowness is coming time to time there can be multiple reasons
  1. Some asshole downloading stuff from the internet since you haven't controlled that
  2. Network congestion because of the number of users using wifi (not sure how many can be handled using a single AP. You need to check that)
1. we have no control or monitoring in place. this may be the issue..
2. tplink 450mbps access point. two of them handling user load.

depends on the where the network bottleneck is
btw what's the internet link in the office? is there any monitoring done on this uplink?
is it going through a firewall? is your server segment located in a seperate vlan or is everything located in the same lan?
I think it would be better if you post a rough diagram with link info.
I doubt it's a problem with your cabling
slt fiber connection. no monitoring done on uplink.
not going trhough firewall
all are in same lan
no cabling is done. all laptop are connected via wifi. only server is connected with cable.
------ Post added on Apr 15, 2021 at 11:46 PM


Attachments

  • 1.jpg
    149.8 KB · Views: 41

tharakaf

Well-known member
  • Oct 19, 2020
    2,785
    5,433
    113
    1. we have no control or monitoring in place. this may be the issue..
    2. tplink 450mbps access point. two of them handling user load.


    slt fiber connection. no monitoring done on uplink.
    not going trhough firewall
    all are in same lan
    no cabling is done. all laptop are connected via wifi. only server is connected with cable.
    ------ Post added on Apr 15, 2021 at 11:46 PM
    If you got the budgets try to buy a fortigate firewall. A entry level one will do. You can replace tplink switch the firewall. It will act as a router and a firewall. Will also provide you monitoring and control as well.

    • Like
    Reactions: vito and Shenal2025

    Shenal2025

    Member
    Jun 26, 2018
    14
    8
    3
    Client Lap ekaka windows update ekak giyath oya wage network ekak slow wenawa.. PfSense wage firewall ekak dala per IP speed limit kraganna :) AP & Switches wala bottleneck thiyennath puluwan.
    ow. oya seen eka wenawa kochchara update nawaththala thibath samahara welawata.. pfsense eka server ekata dala server eka haraha internet denna puluwanda..


    Shenal2025

    Member
    Jun 26, 2018
    14
    8
    3
    ethakota ape server machine ekata network port dekak set karanna ona ne.. ekak router ekata server eken. anith eka switch ekata.. server eka thama firewall eka widihata inne..

    switch.
    issue එක තියෙන්නේ wifi AP වල ද කියලා isolate කරන්න ඕනේ.
    isolate karama issue ekak ne.. laptop ekak dekak use karana kota.
    ------ Post added on Apr 15, 2021 at 11:58 PM


    thinking_guy

    Well-known member
  • Apr 16, 2011
    5,206
    2,866
    113
    Godak welawata AP eken case eka enawa atte. QoS enable welada kiyala balapan. Oyawage case ekak wela Aerohive AP122 model eka dammama hari giya. Gaana tikak wadi.

    • Like
    Reactions: Shenal2025

    lk-maare

    Well-known member
  • Nov 16, 2014
    4,698
    1,907
    113
    මහනුවර
    ethakota ape server machine ekata network port dekak set karanna ona ne.. ekak router ekata server eken. anith eka switch ekata.. server eka thama firewall eka widihata inne..


    isolate karama issue ekak ne.. laptop ekak dekak use karana kota.
    ------ Post added on Apr 15, 2021 at 11:58 PM
    Router > firewall (Server) > Switch + AP's.

    • Like
    Reactions: Shenal2025

    pga

    Well-known member
  • Oct 4, 2006
    4,069
    907
    113
    internet slow kiyana welawata fileserver eken file ekak download karala balanna kiyanna,
    eke awlak nattan e kiyanne network setp eke awlak na but internet attatama slow. eke awlak tibboth AP/Switch wala case ekak wenna ona.

    SLT router ekata log wela router eke CPU/Memory utilization eka balanna.
    Status eken network bandwidth ekath balanna puluwan.

    umbe switch eke port mirroring features na. eka nisa traffic eka analyse karanna one nan SLT router eke admin log wunama port mirroring option ekak tiyenawa. mama use karala nan na. try ekak deela balanna.

    • Like
    Reactions: Shenal2025

    rajitha_5j

    Well-known member
  • Nov 1, 2009
    516
    320
    63
    gampaha
    AP deka direct slt router connect karala balanna. All 30 laptops disconnect karala ekin eka connect karala youtube wage deyak ply karana gaman speed test karanna PC ekaka network virus ekak aty.

    • Like
    Reactions: Shenal2025

    tharakaf

    Well-known member
  • Oct 19, 2020
    2,785
    5,433
    113
    ethakota ape server machine ekata network port dekak set karanna ona ne.. ekak router ekata server eken. anith eka switch ekata.. server eka thama firewall eka widihata inne..


    isolate karama issue ekak ne.. laptop ekak dekak use karana kota.
    ------ Post added on Apr 15, 2021 at 11:58 PM
    Machan, Get your company to invest a bit and setup a proper secure network machan (proper firewall. Cheap working options would be fortigate. A good AV etc.). It might cost a bit but It is worth the trouble. You guys seem to be fucking unsecure and trust me slow internet is the least of your problems. The day you get hit by some ransomware or something is when you start shitting your pants.

    • Like
    Reactions: vito and Shenal2025

    waparc

    Well-known member
  • Jan 12, 2008
    1,843
    652
    113
    මගේ කාමරේ
    මුලින්ම ඉන්න users ලා දෙන්නෙක් temporary Ethernet cable දාලා direct switch එකට connect කරලා දවස් කීපයක් වැඩ කරන්න දීලා බලන්න slowness එක එනවාද කියලා. ඒත් slowness එක තියනවා නම් ගොඩක් වෙලාවට SLT fiber line එකේ අවුලක් වෙන්න පුලුවන්. එහෙම නම් SLT එකට complain 1 දාල ඒක හදාගන්න. Direct switch එකට connect කරපු අයට හොඳට වැඩ නම්. අවුල තියෙන්නේ wifi වල.

    ඔය දාලා තියන access point home use වලට හදපුවා. ඔය වගේ වැඩකට ගැලපෙන්නේ නෑ. Concurrent users ගාන වැඩි වෙනකොට issues එන්න පුලුවන්. අනික ඕක support කරන්නේ 2.4GHz විතරයි. 450Mbps කියන්නේ මාකටින්. real world එකේ ඔය users ලා ප්‍රමානෙත් එක්ක හම්බවෙන්නේ aggregate 20-30Mbps අතර. Ruckus, Aruba, cisco (non SMB) වගේ dual band enterprise AP එකකට මාරුවෙන එක තමයි හොඳ. ඒවා ටිකක් ගනන්. ඔය වගේ workload වලටම හදලා තියෙන්නේ.

    අනිත් අයත් කියල තියනවා වගේ පස්සේ පොඩි ෆයර්වොල් එකකුයි endpoint protection එකකුත් දාගත්තානම් කිසි කරදරයක් නෑ
