ALIENWARE AREA 51 ALX
+ 3 way SLI
Technical Specifications
Operating Systems
* Windows Vista® Ultimate
* Windows Vista® Home Premium
* Windows® XP Media Center Edition 2005
* Windows® XP Professional
Processors, Chipset & Memory
Intel Core 2 Extreme
* Intel Core 2 Extreme Processor with Quad Core Technology
* Extreme 3.0GHz, 1333MHz FSB, 1 x 8MB full-speed level 2 Cache - Overclocked to 3.33GHz
* NVIDIA nForce 680i SLI
* Standard 2GB Dual CHannel DDR2 SDRAM at 800MHz
* Up to 4GB of system memory
Graphics & Video
* Standard Dual NVIDIA GeForce 8800 GTX SLI
o 2 x 768MB GDDR3 dedicated video memory
o Quad DVI and S-Video outputs with quad-display support*
o Full DirectX® 10 and OpenGL® 2.0 graphics compatibility
o NVIDIA SLI-Enabled
o
*Dependant upon graphics configuration
* Optional 3x NVIDIA® GeForce™ 8800 Ultra
o 3-Way NVIDIA® SLI Enabled
o Up to 3x768MB GDDR3 a total of 2.3 Gigabytes of dedicated video memory
o 6x DVI and 3x S-Video outputs with support for up to six displays
o Full DirectX® 10 and OpenGL® 2.0 graphics compatibility
NVIDIA SLI and GeForce 8 Series
* Connectivity
o Video out: Four DVI Connectors
o TV out: Two S-Video Out Connectors
Storage
* Hard Drive Options
o RAID: Options 0 and 1 Available
o RPM: Starting at 7,200 up to 10,000
o Capacity: Starting at 160GB up to 1TB per Drive (4 Drives Maximum)
o Solid State – up to 128GB
o Interface: Serial ATA 3Gb/s
4 Drives Maximum
* Optical Drive Options
o Standard 20x Dual Layer DVD±R/W Drive
o Optional 20x Dual Layer DVD±R/W Drive w/LightScribe Technology
o Optional 6x Blu-ray™ Disc (BD-ROM) Reader
o Optional 4x Blu-ray™ Disc (BD-ROM) Reader / Writer
* Digital Media
o Optional 28-in-1 digital media reader / writer
Networking
* Integrated Dual High Performance Gigabit Ethernet Ports
Dual High Performance Gigabit Ethernet Ports
Audio
* Standard High Definition Surround Sound Audio
o Supports 8–channel (7.1) 24–bit audio
* Optional Sound Blaster X-Fi High Definition Surround Sound Audio
o Supports 8-channel (7.1) 24-bit high-definition audio
o Up to 64MB dedicated Audio XRAM
* Connectivity - Standard Audio:
o Eight-channel analog jacks (Rear)
o One Optical digital output (Rear)
o One 1/8" analog headphones jack (Front)
o One 1/8" analog microphone jack (Front)
Peripheral Connects
USB 2.0 And Firewire IEEE 1394a
* One PS/2 keyboard port
* One PS/2 mouse port
* Two FireWire 400 port (Front)
* Eight Hi-Speed USB 2.0 ports (6 Back / 2 Front)
USB 2.0 And Firewire IEEE 1394a
Case & Chassis
* Exclusive Alienware ALX P2 chassis design in choice of four high-gloss color finishes
* Exclusive chrome-finished chassis accents and black-anodized chassis interior
* AlienIce™ 3.0 high-performance cooling
* AlienFX for quick and easy system lighting
* Easily accessible front ports: two USB 2.0, one FireWire 400, Headphones and Microphone
* Optional 1200 Watt PSU - Standard with NVIDIA 3-Way SLI
* Tool-less front and side panels
* Height: 19.01”
* Width: 9.97”
* Depth: 25.02”
for more info : www.alienware.com
